Aluminum Smelting furnace

Product Category

Application:

Our company supplies aluminum smelting reverberatory furnaces(usually rectangular furnaces), aluminum smelting shaft furnaces, Aluminum holding furnaces. It is suitable for the smelting of primary alloy or secondary alloy. Our furnace may able to take care smelting and holding in one. The configuration can be customized according to the different needs of customers.

Smelting reverberatory furnace: 8T-60T

Aluminum smelting shaft furnace:5T-7T

Aluminum holding furnace:6T-18T



25T reverberatory furnace:

No Item Name Note
1 Products and capacity Capacity: 6T/h

3, 6 and 8 series aluminum alloy rod

Pure aluminum ( EC Grade)

2 Raw material A00 aluminum ingots + return scrap
3 Fuel NG

Heat value ≥8400Kcal/m3;

<60 Nm³/ton.Al

GPL

Heat value ≥26000Kcal/Nm³;

<18Nm³/ton.Al

4 Ingot burning loss   0.5-0.8%
5 Overhaul repair time   ≧ 5 years
6 Combustion system life

regenerative room ≧3 years;

burner ≧2 years

7 Furnace weight   150Tons



6T/h shaft furnace:

No Item Name Note
1 Products and capacity Capacity: 6T/h 6101-6201 aluminum alloy
2 Raw material A00 aluminum ingots (15~20kg) Heat value ≥26000Kcal/Nm³;21~22.6Nm³/ton.Al
3 Fuel GLP
4 Ingot burning loss   2.5%
5 Overhaul repair time   ≧ 4 years
6 Combustion system life   burner ≧2 years
7 Furnace weight   60Tons
